ZAYER ARION

45º HEAD (PATENTED)
AUTOMATIC ROTATION HEAD, POSITIONING EACH 0,001º / CONTINUOUS ROTATION

• Automatic indexing of the cutting tool at any position, positive angles.
• Easy programming.
• High machining performance.
• Machining rigidity.

HEAD

30º HEAD (PATENTED) AUTOMATIC ROTATION HEAD, POSITIONING EACH 0,001º / CONTINUOUS ROTATION

• Automatic indexing of the cutting tool at any positive angles and up to 30º negative angles.
• Easy programming.
• Short distance to the center of rotation, improves accuracy.
• Machining of complex areas with difficult access
• High capacity for working
• Machining rigidity.

ROLL

GUIDEWAYS WITH LINEAR ROLLER PACKS WITH ADJUSTABLE PRELOAD

• Great rigidity.
• Easy geometric adjustment of the machine.
• Simple preloading.
• Simple and reliable exchanging roller packs.

ZMH

EXCHANGABILITY OF DIFFERENT TYPES OF MILLING HEADS

• Selection of milling heads according to the type of machining

BOX

Ram guided in the four sides

VDP

DESIGN OF MACHINES KEEPING THE GEOMETRY IN THE COMPLETE MACHINING VOLUME.

• Very accurate structure of the machine with no need for electronic compensation

ECO

MACHINE DESIGNED CONSIDERING THE ENVIRONMENT

• Long-term lubrication with grease
• Weight reductions
• Driving systems optimized to reduce energy consumption
• Using coolant liquids with no impact to the environment

APPS

SIMPLE TECHNOLOGICAL APPLICATIONS FOR COMPLEX MACHINING
